100% ALUMINIUM
6063 Canadian Aluminum Production offering strenght and elegance where it matters most, at your home!
ADJUSTABLE LOUVRE
Full 6063 Aluminum Extrusions, Load Tested for Canadian climate offer 90degree rotation. Open or close, or just adjust.
Mr Pergola Offer You a few choices
Classic Pergola
MODERN (Integrated gutteres)
WHAT'S THE DIFFERENCE?
Classic Pergola | Modern Pergola | |
|---|---|---|
Adjustable Louvres | ✓ | ✓ |
Louvres Lock at any angle | ✓ | ✓ |
Manual Mechanism |  | |
Electric Mechanism Option |  | |
Built in rails for curtains (left to right) | ✓ | ✓ |
Electric Curtains (vertical movement) | ✓ | ✓ |
Heavy Gage Aluminum | ✓ | ✓ |
Rain Run Off | Any direction of louvres | Integrated Gutters |
Span (distance between posts), both deep and wide | up to 20ft | up to 20ft |
Grade 8 Bolts (McMaster: 90128A714) | ✓ | ✓ |
4 Season Capable | ✓ |
WHAT IS MR. PERGOLA
Mr. Pergola is a solid bioclimatic, rotating louvred pergola for your backyard or patio that will change your home forever. Summer no longer too hot, rain no longer a problem…and winter? Enjoy a snowless patio allowing you to BBQ or a small fire-pit under a blanket enjoying fresh air instead of being inside for months.
Mr. Pergola
MADE IN CANADA WITH CANADIAN ALUMINUM AND AMERICAN STEEL.
Classic
Modern
Commercial
Commercial-Double
Classic-Attached
WHAT WE OFFER
Mr.Pergola offers you two choices. For those who want to use their space in winter, without any snow or worry, you have the Mr.Pergola 4 Season Option. This extremely strong system took two years to develop. Working with engineers, we designed and manufactured it to Canadian Building Code standards. Our mechanism come from and is built in Germany. You can stop it at any angle, not only open or close. Literally any angle to get the most light without the harmful direct rays from the sun.
Mr.Pergola offers you three choices. A Classic Design in 3 or 4 Season option and a sleek Modern design for those who like a more contemporary look.
Classic Design with louvres showing and water falling from the top in any direction you choose. The Classic Design comes in two variaties, 3 or 4 Season usage. 3-Season pergola needs to have the louvres open/vertical when snow fall begins, whereas the 4-Season option allow you to enjoy the area without any snow. The 4-Season is primary bought by customers who are putting the pergola on their patio right outside their door so that they can use their BBQ/Outdoor Kitchen in winter, or use the area for storage. The 4-Season can handle up to 36” of snow.
Second, The MODERN Pergola. This option is for those who want the sleek look because it would fit their house style, or simply a question of taste. Just as our Classic, it is purpose built with tough material for the North American market. The MODERN is not as customizable as the Classic as it needs to remain a square or rectangle. We cannot use cantilevered louvres or extensions (still wall mountable). It’s all boxed in and the water flows down the columns. The direction of the water flow can be changed with the shims that come with the pergola. You can have the water flow down the front/side/back… you decide!
All our pergolas come with a standard manual gearbox. This is no ordinary gearbox, it is made in Germany from a company called LockDrives. It is a 6000n gearbox that will last as long as the pergola itself without ever giving you troubles. For a small additional amount you can opt for the electric Somfy motor.
***REMEMBER, NONE OF OUR PERGOLAS COME IN A BOX FROM CHINA!***
| STANDARD SIZES (4-Post or Wall Mount) | ||||||
|---|---|---|---|---|---|---|
LOUVRES / DEPTH |
WIDE | |||||
| 12 | 14 | 16 | 18 | 20 | ||
| 10 | 12 x 10 | 14 x 10 | 16 x 10 | 18 x 10 | 20 x 10 | |
| 12 | 12 x 12 | 14 x 12 | 16 x 12 | 18 x 12 | 20 x 12 | |
| 14 | x | 14 x 14 | 16 x 14 | 18 x 14 | 20 x 14 | |
| 16 | x | x | 16 x 16 | 18 x 16 | 20 x 16 | |
| 18 | x | x | x | 18 x 18 | 20 x 18 | |
| 20 | x | x | x | x | 20 x 20 | |
Free Customization (cut to fit)
Our 4-season pergola can handle 80 POUNDS OF SNOW and/or ICE per square foot! That’s the equivalent of 24” of WET SNOW! The heaviest type of snow, or 36” of POWDER SNOW. Since snow accumulation is very rarely of uniform makeup, you should not fear the accumulation as we used the Greater Montreal snow fall accumulation as our guide. The slope on our pergolas ensures that there is a constant drip of snow/water dripping down on any sunny day, even when it’s -10 degrees Celsius (black pergolas do better). Thanks to those odd days of +1 to +4 degrees every winter, the snow accumulation is offset on a regular basis.
Our 3-season Pergola is also quite extraordinary. It is the strongest pergola on the market. It lacks the internal reinforcements of the 4-season model but is still built with 6063 and 6061 Aluminum Extrusions, NOT Sheet Metal! The brackets are slightly thinner since it does not need to handle the weight, but make no mistake, it will be stronger and last longer than any pergola on the market. BAR NONE! It can handle any regular first snowfall (2-4cm). They will not bend or break when snow falls from your roof onto the open pergola or if ice accumulates on the blades. Ideally, you leave the blades, what we call “louvres” in our industry, up/vertical before the first snowfall and wait until spring to rotate them again at your leisure.
“THE ONLY COMPANY OFFERING A PERGOLA THAT CAN GO TO 20’X20’ SPAN (WIDTH AND PROJECTION) WITH 4 COLUMNS.”
Text for option 1: Height extension/lowering. Our standard column, head clearance walking in, is: Classic 90”/Modern 96”. The interior height is a further 18” for the Classic and 14” for the Modern. Should you require a pergola that, for example, needs additional height to clear a window, you can order the height extension and choose another height up to 126”. We customize for free and only charge the material.
Text for option 2: Our Classic pergola can be customized to form an L-Shape. This image shows a 24ft deep section with a 14ft deep section. Up to 20ft, you do not need an additional support column. Over 20ft deep, a 4-Season pergola would require one that can be removed in the summer. This is an example of us going further than traditional sellers to accommodate a client.
Text for option 3: This pergola has both extended subframes and extended louvres for a cantilever effect. It can be on 1-2 or all sides. Combined with other options as well.
Text for option 4: Similar to option 3, this pergola can have cantilevered louvres and subframes, while also being wall mounted.
WHAT'S THE DIFFERENCE?
3-Season | Louvres open in winter | 4-Season | Louvres closed in winter | |
|---|---|---|
6063 Aluminum Beams | ✓ | ✓ |
Additional Support Beams | If necessary or desired for lights/heaters | ✓ |
Extrusion Profiles | 6″ | 6″ |
Aluminum Post 6061 | ✓ | ✓ |
Support/”Brackets”-Thickness | 1/8″ | 1/4″ |
Compatible Accessories | ✓ | ✓ |
Internal Reinforcements | 18″ and over | ✓ |
Dynamic charge (constant wind-closed louvres) | 208KM/HR | 208KM/HR |
Static charge (Snow) | First snow fall only (2-4) | 36″/88lbs |
